B3AA-X

3rd series Garden Spot Lighting IP65
· Garden or landscape accent uplighting shines upward to illuminate an object or surface for dramatic, attention·getting visuals. Adjustable fixture and assure the best heat dissipation. It's provided with bracket or spike for wall/ground/grassland mounting.
· extreme narrow beam angle 3˚
· Dimmable Support : Triac / PWM / 1-10V / Dali / DMX512
· CNC aluminum front cover and lighting body.
· Incl. aluminum ground base/spike.

· Power : 8W
· Lighting Source : High Power LED
Single Color : Cree XML White
· LED Driver : CV input, CC output
· LED CCT : 3000K/4000K/6000K
· Optics :
symmetric: 3˚
· Housing : 6063# CNC aluminum with anodized
· Front Cover : 6063# CNC aluminum with anodized
· Finishing Color : Black/Silver/Grey(powder coating)
· Light Window : tempered glass

info

downloads

· Power Cable :
H05RN·F 2x0.75 mm² / L=2m (low voltage)
H05RN·F 3x0.75 mm² / L=2m (high voltage)
· Mounting Parts : aluminum ground base or spike
· Optional Accessory :
Glare Shield
Light Grille
Heightening Pole
· Operating Temperature : ·20˚C~40˚C
· Certifications : CE / RoHS / IP level
· Special surface treatment option : PVDF painting / Dacromet
· Custom Order Loghting(COL) : YES
· Outdoor Perfect Dimming(OPD) : YES
* OPD must work with LEDBEES decoder, for more information please contact us
< >
