PTL

3rd series Garden Spot Lighting IP65
· Garden or landscape accent uplighting shines upward to illuminate an object or surface for dramatic, attention·getting visuals. Adjustable fixture and assure the best heat dissipation. It's provided with bracket or spike for wall/ground/grassland mounting.
· Portable powerful spot with narrow beam angle.
· COB Led CITIZEN super bright.
· Self·owned X heat sinker.
· CNC aluminum front cover and lighting body.

· Power : 50W
· Lighting Source : High Power LED
Single Color : CITIZEN COB
· LED Driver : CV input, CC output
· LED CCT : 3000K/4000K/6000K
· Optics : reflecter
symmetric: 12/24/36˚

· Housing : 6063# CNC aluminum with anodized
· Front Cover : 6063# CNC aluminum with anodized
· Finishing Color : Black/Silver/Grey(powder coating)
· Light Window : tempered glass



info



downloads

· Power Cable :
H05RN·F 2x0.75 mm² / L=2m (low voltage)
H05RN·F 3x0.75 mm² / L=2m (high voltage)
· Mounting Parts : (Portable)
· Optional Accessory : N/G

· Operating Temperature : ·20˚C~40˚C
· Certifications : CE / RoHS / IP level
· Special surface treatment option : PVDF painting / Dacromet
· Custom Order Loghting(COL) : YES
· Outdoor Perfect Dimming(OPD) : YES
* OPD must work with LEDBEES decoder, for more information please contact us
