B1S

1st series Wall Mounted Lighting IP65
· Wall mounting fixture, with compact and minimalistic design. It can be equipped with built·in driver. It is has an IP65 protection rate solid housing. Available in two versions : single and double light emission, and different optics available.
· Premium heat·sink system inside.
· RGB / RGBW multi·in·one LED.
· Dimmable Support : Triac / PWM / 1·10V / Dali / DMX512
· Solid steel lighting body.
· Incl. steel mounting base.

· Power : 20/40W
· Lighting Source : High Power LED
Single Color : Cree XPE2 / Cree CXA COB
RGB : Epistar RGB3in1
RGBW : Cree XML COLOR
· LED Driver : CV input, CC output
· LED CCT : 2700K/3000K/4000K/6000K
· Optics :
Lens: 6/8/10/15/25/45/60/90˚
Reflecter: 12/24/36˚
· Housing : Plated steel with powder high temperature coating
· Front Cover Color Option : Grey / Black / White

info

downloads

· Power Cable :
H05RN·F 2x0.75 mm² / L=0.5m (low voltage)
H05RN·F 3x0.75 mm² / L=0.5m (high voltage)
H05RN·F 4x0.75 mm² / L=0.5m (RGB PWM)
H05RN·F 5x0.75 mm² / L=0.5m (RGBW PWM)
· Mounting Base : steel mounting base
· Operating Temperature : ·20˚C~40˚C
· Certifications : CE / RoHS / IP level
· Special surface treatment option : PVDF painting / Dacromet
· Custom Order Loghting(COL) : YES
· Outdoor Perfect Dimming(OPD) : YES
* OPD must work with LEDBEES decoder, for more information please contact us
< >
