B3BB

3rd series Garden Spot Lighting IP65
· Garden or landscape accent uplighting shines upward to illuminate an object or surface for dramatic, attention·getting visuals. Adjustable fixture and assure the best heat dissipation. It's provided with bracket or spike for wall/ground/grassland mounting.
· RGB multi-in-one LED available.
· Dimmable Support : Triac / PWM / 1-10V / Dali / DMX512
· Aluminum front cover and lighting body.
· Incl. aluminum ground spike.

· Power : 15~25W
· Lighting Source : High Power LED
Single Color : Cree XPE2
RGB : Epistar RGB3in1
· LED Driver : CV input, CC output
· LED CCT : 2700K/3000K/4000K/6000K
· Optics :
symmetric: 6/8/10/15/25/45/60/90˚
· Housing : 12# Die·casting aluminum with powder high temperature coating
· Front Cover : 12# Die·casting aluminum with powder high temperature coating· Light Window : tempered step glass
· Light Window : tempered glass
· Finishing Color : Black/Silver/Grey(powder coating)

info

downloads

· Power Cable :
H05RN·F 2x0.75 mm² / L=2m (low voltage)
H05RN·F 3x0.75 mm² / L=2m (high voltage)
H05RN·F 4x0.75 mm² / L=2m (RGB PWM)
· Mounting Parts : aluminum ground spike
· Optional Accessory :
Glare Shield
Light Grille
Heightening Pole
· Operating Temperature : ·20˚C~40˚C
· Certifications : CE / RoHS / IP level
· Special surface treatment option : PVDF painting / Dacromet
· Custom Order Loghting(COL) : YES
· Outdoor Perfect Dimming(OPD) : YES
* OPD must work with LEDBEES decoder, for more information please contact us
< >
